Water Driven Turbine Fan Water Driven Exhaust Fan WTF-300/WTF-400
Water Driven Turbine Fan/Water Turbine Fan
WTF-300/ WTF-400
Water Driven Turbine Fans are ideal for releasing gases from tanks.The ships water line is connected through standard 50A connections.
This product have wide applicability, and are ideal for expelling poisonous or other harmful gases from enclosed areas such as tanks, holds etc.
Designed for high performance ventilation of gas from large enclosed areas or other tank openings. Works effectively providing penetration deep into the tank for complete ventilation. Made of a non-spark construction with a line impeller and integral water motor that are coated against corrosion.
Inlet/outlet water hoses are sold separately
| MODEL | WTF-300 | WTF-400 |
| RecommendedWater Pressure | ≥7kg/c㎡ | ≥7kg/c㎡ |
| Water inletand outlet | 2" | 2" |
| Air Flow M³/H | 3000-6000 | 4000-10000 |
| Out Bore Diameter MM | 300 | 400 |
Main Accessories:
1. Assembled unit: Casing,Motor ,Impeller and other parts
2. Handle, 2 pc.
3. 2"BSP(F)x2"BSP(M)Elbow-90°, 1 pc.
4. 2" BSP (M) x 1-1/4" BSP (M) Inlet Pipe, 1 pc.
5. 2" BSP (F) x 2" BSP (M) Outlet Pipe, 1 pc
6. Adaptor 1 pc
| DESCRIPTION | UNIT | |
| TURBINE FAN WATER DRIVEN, MODEL KWF-300M 70-220M3/MIN | SET | |
| TURBINE FAN WATER DRIVEN, MODEL KWF-400M 100-290M3/MIN | SET |
